Description Product Brochure Specifications Connections NetworkEthernet-10/100BaseT compatible (required for controller setup), PoE supported WirelessWireless N (2.4 GHz, 802.11n/g/b) Wireless SecurityWEP, WPA, and WPA2 Wireless antennaExternal reverse SMA connector ZigBee Pro802.15.4 ZigBee antennaExternal reverse SMA connector USB port2 USB 2.0 ports, 500mA Serial out1 serial out RJ45 port (RS-232) Z-WaveIntegrated expansion slot accepts Control4 Z-Wave modules (sold seperately) Z-Wave modulesC4-ZWE, C4-ZWH, C4-ZWU (sold seperately) Power Power requirements5VDC 3A, external power supply included Power supplyAC power supply accepts 100-240V 50-60Hz (0.5A) PoE802.3af (<13W) Power consumptionMax 15W (51 BTU/hr) Miscellaneous Operating temperature32˚ ~ 104˚F (0˚ ~ 40˚C) Storage temperature4˚ ~ 158˚F (-20˚ ~ 70˚C) Dimensions (W x H x D)140 x 140 x 38mm (5.5″ x 5.5″ x 1.25″) Weight0.3kg (0.65 lbs) Shipping weight0.68kg (1.5 lbs)
