Description Features Specifications • Controls up to eight 0-10V dimmable fluorescent ballasts or LEDs.• Sink up to 100mA per channel for control of up to 50 ballasts or source up to 25mA per channel for control of up to 12 ballasts.• Eight low-voltage outputs for triggering external power relays.• Channel buttons allow for toggling on/off or ramping up/down a load.• Channel status LEDs indicate whether a load is on or off.• Module override button allows toggling between the module override scene and all channels off or setting the module overridescene to current channel levels.• Module status LED indicates if module power is on with normal operation or off.• Auxiliary override connection allows a standard line-voltage toggle switch to control the attached lights before the control systemis installed or in case the controller malfunctions.• The module can be installed in either a Control4 5-slot or 2-slot panel or in a third-party DIN rail panel. Model numberC4-DIN-8TV-E Power requirements100-277VAC, 50/60 Hz 0-10V per channel max100mA, sink (approximately 50 ballasts—see ballast specifications) 25mA source (approximately 12 ballasts—see ballast specifications) External relay channel rating24V max, 50mA max Power consumption2.5W Supported load types0-10V and 1-10V dimmable fluorescent ballasts and LEDs, sink, or source Control communcationsEthernet Operational temperature32˚F ~ 104˚F (0˚C ~ 40˚C) Humidity5% – 95% non-condensing Storage temperature -4˚F ~ 158˚F (-20˚C ~ 70˚C) Heat dissipation9 BTU/hr @120VAC H × W × D8.5 × 4.3 × 2.3 in. (215 × 109 × 57 mm) DIN module width12M Weight2.4 lbs. (1.1 kg) Shipping weight2.90 lbs. (1.3 kg)
