Expert FeaturesReverse PoE Design (7 In 1 Out)Powered via PoE on up to 7 input ports, delivering power and data through a single cable, with 1 PoE output port to power another device—ideal for flexible deployments where power outlets are limited.Full Gigabit PerformanceAll 8 RJ45 ports support 10/100/1000Mbps auto-negotiation, ensuring fast and stable data transmission for IP cameras, access points, routers, and network devices.Non-Blocking Switching CapacityWith 16Gbps switching bandwidth and 11.904 Mpps forwarding rate, the switch delivers smooth, full wire-speed performance without congestion.Store-and-Forward ArchitectureEnsures reliable packet transmission with error checking, improving overall network stability and data integrity.Long & Standard Cable SupportSupports up to 250m at 10Mbps and 100m at 100/1000Mbps using standard CAT3/4/5 UTP cables.Jumbo Frame SupportHandles 9216-byte jumbo frames, improving efficiency for large data transfers and reducing CPU load on connected devices.Energy Efficient & Low Power ConsumptionConsumes ≤3W, making it suitable for continuous operation in small network environments.Simple Plug & Play OperationNo configuration required. Automatic MDI/MDIX, half/full duplex auto-adaptation, and LED indicators for easy monitoring.Compact & Durable DesignSpace-saving form factor ideal for desktop, cabinet, or embedded installations in offices, surveillance systems, and telecom setups.Expert SpecsSpecificationDetailsBrandDT ReliableModelSG08RP-2SProduct TypeReverse PoE Gigabit SwitchPorts8 × RJ45 (7 PoE In 1 PoE Out)Ethernet StandardsIEEE 802.3, 802.3u, 802.3abOther ProtocolsIEEE 802.1p, IEEE 802.3xData Rate10/100/1000 Mbps Auto-NegotiateForwarding MethodStore-and-Forward (Full Wire-Speed)Duplex ModeHalf / Full Auto-AdaptiveSwitching Bandwidth16 Gbps (Non-Blocking)Packet Forwarding Rate11.904 Mpps @ 64 bytesMAC Address Table4KBuffer Memory1.5 MBJumbo Frames9216 bytesPoE Pin Assignment4/5 ( ), 7/8 (–)Input Voltage14V – 48V DCPower Consumption≤ 3WLED IndicatorsPower, Ethernet Link/ActivityTransmission Distance250m (10Mbps), 100m (100/1000Mbps)
