Machine Type A3 Monochrome Laser Multifunctional Core Functions iR2224N: Print, Copy, Scan, and Send iR2224: Print, Copy, and Scan Control Panel 3.5 inch monochrome touch panel Memory 1.0 GB RAM Storage eMMC: 2 GB Interface Connection NETWORK*1 Standard: 100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)OTHERS Standard: USB 2.0 (Device) x1 Paper Supply Capacity (A4, 80 gsm) Standard: 350 sheets (Paper Drawer: 250 sheets, MPT Tray: 100 sheets) Maximum: 600 sheets (with Cassette Feeding Module-AK1) Paper Output Capacity (A4, 80 gsm) Standard: 250 sheets Maximum: 250 sheets Supported Media Types Multi-purpose Tray: Thin, Plain, Recycled, Thick, Colour, Bond, Label, Pre-punched, EnvelopePaper Cassette: Plain, Recycled, Colour, Pre-punched Supported Media Sizes Multi-purpose tray: A3, A4, A4R, A5, A5R, B4, B5, B5R, Envelope (COM10, Monarch, DL, ISO-C5), Custom size min. 95.0 x 148.0 mm up to 297.0 x 431.0 mmPaper Cassette: Standard size: A3, A4, A4R, A5R, B4, B5, B5R Supported Media Weights Multi-purpose tray: 60 to 157 gsm Paper cassettes: 64 to 90 gsm Duplex: 60 to 90 gsm Warm-up Time From Power On: 13 seconds or less*2 *3 From Sleep Mode: 4.3 seconds or less Dimensions (W x D x H) iR2224N (with DADF): 627 x 607 x 606 mm iR2224/2224N (with Platen cover): 627 x 589 x 502 mm iR2224N (with DADF and cassette): 627 x 607 x 698 mm iR2224N (with Platen cover and cassette): 627 x 589 x 594 mm Installation Space (W x D) 1065 x1285 mm Weight iR2224N: Approx. 30.3 kg without toner and Platen cover iR2224: Approx. 31.6 kg without toner and including Platen cover
