QYT DWC30WIN 30A 13.8V Power Supply Radio Switching Transceiver for KT-780Plus TH-9800 KT-7900D 8900D TYT ICOM Car Radio

High Efficiency QYT DWC30WIN 30A 13.8V Power Supply Radio Transceiver for KT-780Plus TH-9800 KT-7900D 8900D TYT ICOM Car Radio Features Precision voltage regulator, the output DC accuracy of ≤ 1% * Wide operating voltage range * Automatic over-voltage protection, if the output voltage is higher than the normal output voltage, will automatically cut off the power output to ensure that your radio security . * Automatic over-current protection, if the output current is greater than the maximum or load short-circuit , it will automatically cut off the power output, to ensure that your power will not burn out. Technical performance. Input power supply voltage: AC220V ± 10% (NOTICE: this is AC 220V Device, can not use for AC 110V, USA, Canada customer please notice) Rated output voltage: DC13.8Vv ± 10% Maximum output current: 30A Charging current: 1A ± 0.5% Ripple coefficient output: ≤ 10mVP-P Output voltage accuracy: ≤ 1% Output Load Accuracy: ≤2% Color screen, display volt and current meter. Adjust voltage between 8.0 and 16.0 V. The built-in cooling fan keeps everything cool and the power flowing. Screw terminal connectors. Perfect for home, shop, ham/CB radio. Specifications: Input voltage:220V AC Output voltage: 13.8DC adjust voltage between 8.0 and 16.0 V. turn clockwise to increase and counter clockwise to decrease the voltage. when it is set at the center position it will supply 13.8V Output voltage regulation :less than 2% Protection: short-circuit, automatic current limiting within 30A Output current:30A(max) 20A(continuous ) Ripple: less than 80mVp-p at rated load. Fuse :5A Meter: single volt/current meter ,back-lit Dimensions:6.1x 2.83 x 9.45in/155 x 72 x 240mm Weight: 4.25lb/1.93kg Packing List: 1x Adjustable Switching Power Supply 1x Power Cable (EU plug) 1x user manual
